Owner’s Guide
25
Specifications
• Specifications may be changed without prior notice.
• The capacity may differ slightly, depending on the water pressure, water supply, piping conditions, and water
temperature.
Item Specification
Model
Name
50°C model 26ENG5N 26ENG5L 21ENB5N 21ENB5L 17ENB5N 17ENB5L
55°C model 26ENG6N 26ENG6L 21ENB6N 21ENB6L 17ENB6N 17ENB6L
Type
Installation Outdoor, Wall mounted
Air Supply / Exhaust
Power Flue
Operating Pressure 200 -1,000 kPa
Minimum Flow Rate 1.5 L/min 2.5 L/min
Dimensions (Height) × (Width) × (Depth) 520 mm × 350 mm × 170 mm
Weight 16 kg 15 kg 14 kg
Water Holding Capacity 0.7 L 0.5 L
Connection
Sizes
Water Inlet R 3/4 (20 mm)
Hot Water Outlet R 3/4 (20 mm)
Gas Inlet R 3/4 (20 mm)
Power
Supply
Supply 230 - 240 VAC (50 Hz)
Consumption
NG/ULPG 55.0 W / 60.0 W 36.0 W / 49.0 W 31.0 W / 41.0 W
Freeze
Prevention
106 W 129 W
Burner Injector Size
NG 1.45 mm / 2.1 mm 1.2 mm / 2.0 mm 1.2 mm / 1.8 mm
ULPG 1.0 mm / 1.4 mm 0.9 mm / 1.4 mm
Accessories Anchoring Screws
Item Maximum Performance
Model
Name
50°C model 26ENG5N 26ENG5L 21ENB5N 21ENB5L 17ENB5N 17ENB5L
55°C model 26ENG6N 26ENG6L 21ENB6N 21ENB6L 17ENB6N 17ENB6L
Gas Consumption NG 195 MJ/hr 159 MJ/hr 125.5 MJ/hr
ULPG 195 MJ/hr 159 MJ/hr 127 MJ/hr
Maximum Hot Water Capacity (25°C Rise) 26 L/min 21 L/min 17 L/min
Performances
