Trouble Shooting Guide
The ‘Conditions’, ‘Causes’, and ‘Suggested Corrections’ as indicated below and on the following page(s) are only
a guideline for failures that we have found to be most common.
Though this information is provided in this booklet, it is assumed and expected that any personnel involved in the
servicing of an Air Compressor Unit is knowledgeable with this type of equipment. Do not attempt to service a
Compressor Unit unless you are familiar with it, as there are many issues that may come into play, the most
important being personal safety and the welfare of the Unit.
Should you have any questions, or require servicing to your Unit, please contact your local DV Systems
Distributor.
Condition:
Cause:
Suggested Correction:
A. Unit won’t start. No fuel in Honda Engine.
Honda Engine will not start due to
mechanical issue.
Check Valve / Unloader is not in ‘Locked’ /
‘Start’ position.
Check that Engine has fuel.
Contact local Honda Dealer.
Place Check Valve / Unloader in ‘Locked’ /
‘Start’ position as indicated on Page 9.
B. No or Insufficient Air
Flow.
Air Filter is dirty.
Loose Belts.
Pump Valves, Aftercooler, or Tank Check
Valve leaking, sticking, or plugged.
Air leaks at Compressor or in hose system.
Unit is too small for the compressed air
requirements.
Replace the Air Filter.
Tighten as required. Do not over-tighten.
Clean, repair, or replace.
Fix leaks. Soap/water mixture will assist in
finding small leaks.
Contact your DV Systems Distributor for
assistance.
C. Belts Roll Off Motor
Pulley and/or Flywheel.
Flywheel and Motor Pulley are not aligned.
As two Belts are used, Belts may not be
matched set.
A nick or tear on the edge of a belt.
Belts do not match the Flywheel/Pulley
groove (such as ‘A’ or ‘B’ section).
Align using a straight edge.
Purchase a new set of matched belts.
Purchase a new set of matched belts.
Purchase a new set of Belts, paying close
attention to ‘A’ or ‘B’ section requirement.
When servicing the Air Compressor, shut off all
power to the Unit, and drain it of air pressure.
