Chapter 12
PAN TILT ZOOM
Pan Tilt Zoom (PTZ) provides the administrator of the DVR with the ability to
configure and monitor all PTZ cameras that are connected to the DVR. The
DVR can be configured with multiple PTZ cameras. Currently, the system
supports the following PTZ models:
1. Lilin Protocol: PIH-7000, PIH-7600, PIH-7625
2. Vido Protocol: CD-55
3. Pelco Protocol: Pelco-D and Pelco-P(Pelco Spectra III series)
4. SAE Protocol: CD-55H.CD-56,CD-65
5. PANASONIC Protocol: only support for WV-CS850, WV-CS854
(Traditional Protocol)
6. Dynacolor Protocol: D7722, D77HO
7. MD-Nicecam: MP1000, MD1800
8. Katatel-312 Protocol
The user should contact their dealer for information regarding which PTZ
cameras they can provide at present. This chapter shows users how to con-
figure a PTZ camera that is compatible with the DVR.
1.Click the “PTZ” Tab.
Figure 12-1: PTZ Tab
Chapter 12
