Identifying External Components
Please refer to the text and diagrams below to identify all external compo-
nents and accessories of the Digital Video Recorder.
Front View
Figure 1-1: Front View of the DVR
Front Inside View
Please refer to Figure 1-2 and the following descriptions to identify the
components on the front side of the Digital Video Recorder.
Figure 1-2: Front Inside View of the Digital Video Recorder
4 or 8 Channel Type
12 or16 Channel Type
4 or 8 Channel Type
12 or 16 Channel Type
To Next Page
