Dwyer Instruments LOVE CONTROLS 32A Series User Manual

Page 35
Input Ranges (Field Selectable)
Thermocouple Types
Input
Type
Range
1° F
1°C
Input
Type
Range
1° F
1°C
Input
Type
Range
1° F
1°C
Type J or L*
Iron-Constantan
-100 to +1600
-73 to +871
Type R
PT 13%-PT
0 to 3200
-17 to +1760
Type N*
Ni Chr Si-Ni Si
-100 to +2372
-73 to +1300
Type K*
Chromel-Alumel
-200 to +2500
-129 to +1371
Type S
PT 10%-PT
0 to 3200
-17 to +1760
Type T*
Copper-Constantan
-350 to +750
-212 to +398
Type B
PT 6% RE-PT 30% RE
+75 to 3308
+24 to 1820
Type E*
Chromel-Constantan
-100 to +1800
-73 to +982
Type C
W 5% RE-W 26% RE
0 to 4208
-17 to 2320
* These Input Types can be set for 0.1°
display. If temperature goes above 999.9° or
less than -199.9° the display will return the
whole degree resolution.
RTD Types
Input
Type
Range
1° F
1°C
100 Ohm Platinum
0.00385 DIN
Curve*
-328 to +1607
-200 to +875
100 Ohm
Platinum 0.00392
Nist Curve*
-328 to +1607
-200 to +875
120 Ohm Nickel
0.00628 US Ind.
Curve*
-112 to +608
-80 to +320
1000 Ohm
Platinum 0.00385
Nist Curve*
-328 to +1607
-200 to +875
Process Input Types
The 0 to 20 mAdc, 4 to 20 mAdc, 0 to 10 Vdc, 2 to 10 Vdc, and -10 to +10 mVdc inputs are fully scal-
able from a minimum of 100 counts span placed anywhere within the range of -1999 to +9999. Decimal
point position is adjustable from zero places (9999), tenths (999.9), hundredth (99.99), or thousands
(9.999).
