MODEL IDENTIFICATION
Model 3 2 A
Alarm
Programming
0 = No
1 = Yes
Output 1
1 = SSR 5 = Current
2 = 5 VDC 8 = DC SSR
3 = Relay
Output 2
0 = None 3 = Relay
1 = SSR 8 = DC SSR
2 = 5 VDC
Options
Options:
992 RS-485 Serial Communications. Allows remote computer to read and write all control
parameters.
9502 12 - 24 VDC/VAC 50-400Hz power supply (control operates on low voltage equipment).
Note: Only Option 9502 may be combined with another option. No other options may be
combined.
INSTALLATION
Mount the instrument in a location that will not be subject to excessive temperature, shock, or vibra-
tion. All models are designed for mounting in an enclosed panel.
Select the position desired for the instrument on the panel. If more than one instrument is required,
maintain the minimum of spacing requirements as shown on the drawing opposite. Closer spacing will
structurally weaken the panel, and invalidate the IP66, UL type 4 rating of the panel.
It is not necessary to remove the control chassis from the housing for instal-
lation. If the control chassis is removed from the housing, you must follow
industry standard practice for control and protection against Electro-Static
Discharge ( ESD). Failure to exercise good ESD practices may cause damage
to the control.
