1. Always use recommended solder-less terminals: Fork terminals with isolation
(M3 screw, width 7.0 mm), hole (diameter 3.2 mm). Screw size: M3x6.5 (with
6.8x6.8 square washer). Recommended tightening torque: 0.4 N.m (4kgf.com).
Applicable wire: solid/twisted wire of 2 mm2, 12 AWG to 24 AWG. Please be
sure to tighten them properly.
2. Prevent dust or metallic debris from falling into the device and cause
malfunctions.
3. DO NOT modify or uninstall the device.
4. DO NOT use empty terminals.
5. Make sure the wires are correctly connected to proper terminals.
6. Keep away from high-voltage and high-frequency environment during
installation in case of interference.
7. Prevent using the device in premises which contain: dust or corrosive gas, high
humidity, high radiation, vibration and shock.
8. LCT216 is an open-type device. Make sure to install it in an enclosure to
prevent dust, humidity in case of an electric shock.
9. Please make sure the power cables and signal device are installed correctly
before switching on the power; otherwise serious damage may occur.
10. DO NOT touch the terminals or repair the device when the power is on;
otherwise an electric shock may occur.
11. Please wait for one minute after the power is switched off to allow the capacitor
to discharge and DO NOT touch the internal wiring within this period.
12. Use dry cloth to clean the device. DO NOT use acid or alkaline liquid to clean
the device.
LOVE CONTROLS DIVISION
DWYER INSTRUMENTS INC.
P.O. BOX 338 - MICHIGAN CITY, INDIANA 46360, U.S.A.
Phone: 219/879-8000 www.love-controls.com
Fax: 219/872-9057 e-mail:love@love-controls.com
©Copyright 2015 Dwyer Instruments, Inc Printed in U.S.A. 4/15 FR# 443702-00 Rev. 2
LCT216 is an OPEN-TYPE device. They are intended for installation completely within
an overall panel and for use in counting or timing applications. If it will cause series
injury to workers or damages on other equipment when used in a dangerous environment, please make
sure it is installed in an automatic safety protection device.
WARNING
1. When the power is on, DO NOT touch the AC terminals in case an electric shock
may occur.
2. Make sure the power is disconnected when you check the unit inside.
DANGER
