DX Engineering 4-BTV - Page 3

- 3 -
Chapter 7 - Tuning
Understanding Trap Calibration
43
Hustler
®
Traps
44
Hustler
®
Trap Calibration - Resonance Adjustment Procedure
46
Tuning the 80 Meter Resonator Whip for the 5-BTV and 6-BTV
47
Chapter 8 - Guying the Hustler
®
BTV Antenna System
48
Chapter 9 - Reference Information
Elevated Mounting of the Hustler
®
BTV Antenna
49
The Quarter-Wave Vertical on a Metal Roof
50
What Trap Do I Have?
52
Hustler
®
BTV Replacement Parts Diagram
53
Weatherproofing Coaxial Cable Connections
54
Lightning Protection - For Any Installation
54
Hustler
®
BTV Specifications
55
Chapter 10 - Additional Operating Bands
Adding Additional Operating Bands to your Hustler
®
BTV Antenna
57
Chapter 11 - Recommended Accessory Items
For Assembly
58
For Quick Tilt Action
59
For Tuning
60
Additional Accessories for Your Hustler
®
BTV
61
Technical Support and Warranty
64
Note: DX Engineering is constantly upgrading information and developing new products to
enhance your amateur radio experience. Please check the DX Engineering web site for the
latest information: www.DXEngineering.com
The Hustler
®
Antenna Company introduced this product over 50 years ago, with little attention to
maximizing performance. It was designed to be an easy-to-install antenna with minimal grounding,
which provided easy - or no - tuning and wide bandwidth but mediocre performance.
DX Engineering decided to take this popular product and show how its performance could be
greatly increased by proper installation, including the addition of an adequate radial ground
system. This results in lowering the resonant frequency, and also altering the impedance at
resonance. Hence - the need to adjust the traps, which was not “allowed” by the manufacturer, and
the possible addition of a shunt coil at the feedpoint.
You can install the antenna according to the New-Tronics instructions and make some contacts with
little attention to ultimate performance. Our BTV Guide takes you into areas which result in
departing from the simple installation and the need to make more adjustments than originally
described. That is the reason we designed the tilt base, for easy raising and lowering between
adjustments.
The overall experience should be an effort which started with an inexpensive trap vertical, and
finished with a high performance antenna installation providing very satisfying results.
