Connecting the Optional Power Adapter
An optional 9 Volt, 1.5 A power adapter can also be used to power the label maker.
Connecting the AC adapter disconnects the batteries as a power source.
To connect the power adapter
Plug the power adapter into the power connector on 1.
the top, left side of the label maker.
Plug the other end of the adapter into a power outlet. 2.
Ç Make sure the label maker power is turned o before
you disconnect the power adapter from the main power
source. Otherwise, your most recent memory settings
will be lost.
Inserting the Tape Cassette
Your label maker comes with one tape cassette.
You can purchase additional tape cassettes from
your local office supply retailer.
To insert the tape cassette
Lift the tape cassette cover to open the tape 1.
compartment. See Figure 3.
Ç Before using the label maker for the first
time, remove the protective cardboard insert
from the tape exit slot. See Figure 4.
Insert the cassette with the label facing up and 2.
the tape positioned between the guideposts.
Press firmly until the cassette clicks into place. 3.
See Figure 5.
Close the tape cassette cover. 4.
Guideposts
Figure 5
Click!
Remove
cardboard insert
Figure 4
Figure 3
Click!
