Dymo LabelManager 500TS Quick Reference Guide

3
Charging the Battery
A charging adapter is included with your label maker for recharging the battery
pack. Charging the battery pack will take approximately three hours.
The charging adapter is only used for
recharging the battery pack; the charging
adapter cannot be used to power the
label maker.
To recharge the battery
1 Plug the charging adapter into the power
connector on the top of the label maker.
2 Plug the other end of the charging
adapter into a power outlet.
Make sure to read the LiPo Safety Precautions found on page 15.
Inserting the Label Cassette
Your label maker uses DYMO D1
label cassettes.
To insert the label cassette
1 Lift the back cover of the label maker to
open the label compartment.
2 Make sure the tape and ribbon are taut
across the mouth of the cassette and that
the tape passes between the label guides.
If necessary, turn the ribbon rewind spool
clockwise to tighten the ribbon.
3 Insert the cassette and press firmly until the
cassette clicks into place.
4 Close the back cover of the label maker.

Dymo LabelManager 500TS Specifications

Operating Environment

temperature resistance	-18° to 90° C

Weight and Dimensions

length	490 mm
width	311 mm
height	127 mm
weight	1102 grams
