Dymo LabelManager 500TS Quick Reference Guide

9
Connecting the Label Maker to Your Computer
The label maker connects to your computer using the USB connection located
on the top of the label maker.
Do not connect the label maker to your computer until after the
software installation is complete.
To connect the label maker to your computer
1 Plug the USB cable into the USB port on the top of the label maker.
2 Plug the other end of the USB cable into an available USB port on
your computer.
3 If necessary, press to turn on the label maker.
4 If you have more than one DYMO label printer installed, do the following:
a Click the printer image in the DYMO Label software Print area.
All the label printers that are installed on your computer are displayed.
b Select the LabelManager 500TS label maker.

Dymo LabelManager 500TS Specifications

Operating Environment

temperature resistance	-18° to 90° C

Weight and Dimensions

length	490 mm
width	311 mm
height	127 mm
weight	1102 grams
