Dymo LabelManager 500TS Quick Reference Guide

4
Getting to Know Your Label Maker
Become familiar with the features shown in the following figure.
1 USB connector 8 Return 15 Symbols - Punctuation
2 Power connector 9 Symbols - Currency 16 Home
3 Touch screen 10 Delete 17 On/Off
4 OK 11 Accented characters 18 Cutter
5 Print 12 Space bar 19 Label exit slot
6 Print preview 13 Shift 20 Navigation
7 Backspace 14 Caps Lock
12
3
4
5
6
7
8
10
11
9
12
13
14
15
16
17
18
19
20

Dymo LabelManager 500TS Specifications

Operating Environment

temperature resistance	-18° to 90° C

Weight and Dimensions

length	490 mm
width	311 mm
height	127 mm
weight	1102 grams
