ASSEMBLY INSTRUCTIONS
7. Attach bottle opener (J) to front panel of the
firebox (F) using two M6x15 screw (AA)
8. Thread crank handle (N) into front panel of the
firebox (F). Secure with one cotter pin (HH)
Hardware Used
9. Attach lower lid hinge (C1) to back panel of the
firebox (G) using four M6x35 screw (BB)
G
HH
F
F
N
AA
BB
C1
J
7
8
9
Hardware Used
M6x15 Screw
x 2
AA
Cotter Pin
x 1
HH
Hardware Used
M6x35 Screw
x 4
BB
