Dyna-Glo DGP397CNP-D - Page 9

9
X
FF
G
L
V
EE
G
L
ASSEMBLY INSTRUCTIONS
5. Attach the upper front door brace (V) to the
cart left side panel assembly (L) and the cart
right side panel assembly (G) with four M6x35
bolts (EE).
6. Attach the door magnet (X) to the cart left side
assembly (L) with four M3x10 bolts (FF).
5
6
Hardware Used
Hardware Used
EE
FF
M6x35 Bolt
M3x10 Bolt
x 4
x 4
L
G
FF
X
L
G
EE
V
