9
INSTALLATION
3. Connect the wire to the power block located in the base of the heater - See
Figure 7.
4. Turn on the power at the main service.
NOTE: All wiring must be carried out by a Certied Electrician and must be in
accordance to national and local electrical codes. For certain applications, conduit
may be required, See Figure 7. Check local electrical codes. If you run the wiring in
conduit and wish to be able to turn the heater be sure to purchase enough exible
conduit to allow the heater to be turned.
HIGH TEMPERATURES – RISK OF FIRE. KEEP FLAMMABLE MATERIALS, SUCH AS
FURNITURE, PILLOWS, BEDDING, PAPERS, CLOTHES, ELECTRICAL CORDS AND CURTAINS
AT LEAST 3 FT. (0.9 M) FROM THE FRONT AND TOP OF THE HEATER AND KEEP THEM AWAY
FROM THE SIDES AND REAR. TO REDUCE THE RISK OF FIRE, DO NOT USE IT IN AREAS
WHERE GASOLINE, PAINT OR FLAMMABLE LIQUIDS ARE USED OR STORED.
WARNING
TO REDUCE THE RISK OF FIRE, DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THE HEATER.
WARNING
CONNECTING THE POWER
3. The external temperature control (external thermostat): a certied thermostat
must be used.
4. The lead wire of external temperature control (external thermostat) can not
be less than 14AWG.
TO PROTECT THE HEATING ELEMENT
When starting the heater, turning the temperature control clockwise slowly to desired
heat setting, the unit starts the fan rst then starts the heating element.
When shutting off the heater, turning the temperature control counter-clockwise to off,
both the fan and the heating element turn off at the same time.
THIS APPLIANCE MUST BE GROUNDED!
THE APPLIANCE MUST CONNECT TO A CURRENT PROTECTION CIRCUIT OR DEVICE
BEFORE BEING CONNECTED TO POWER SUPPLY!
WARNING
1. Remove the screw from the front of the unit to connect the power to the heater.
2. Attach the cable connectors to the unit (See Figure 7). Select power supply
wire to comply with local and national electric codes using heater rating given
on the rating label.
To Next Page
