Dyna-Glo LPFA40WH - Page 14

LPFA40WH LPFA60WH
1 INNERSHELLASSEMBLY 1 2304818 2304818
2 NOZZLE 1 *2304829 *2325121
3 FLAMECAP 1 2304819 2325120
4 THERMALSWITCHBRACKET 1 2304826 2304826
5 THERMALSWITCH 1 2201373 2201599
6 NOZZLENUT 1 2304578 2304578
7 SPARKPLUGASSEMBLY 1 2201375 2206033
8 THERMOCOUPLEASSEMBLY(1130/1474425L) 1 2304885 2304885
9 GASTUBINGASSEMBLY 1 2304830 2304830
10 OUTERSHELL 1 2315956 2315956
11
CORDWRAP(selectmodelsonly)
2 N/A N/A
12 HANDLEASSEMBLYBLACK 1 2101447 2101447
12.1 SCREWHANDLEFRONT 1 2001355 2001355
12.2 SCREWHANDLEFRONT 1 2001077 2001077
12.3 NUTHANDLEREAR 1 2000384 2000384
13 MOTORSUPPORT 1 2304823 2304823
13.1 MOTORMOUNTINGBOLT 2 2001332 2001332
13.2 SLEEVE 1 2304949 2304949
14 MOTORASSEMBLY 1 2305909 2304547
14.1 MOTORFAN 1 2304821 2304821
15 FANGUARDBLACK 1 2304828 2304828
16 MOTORBRACKET 1 2304937 2304937
17 VALVEGAS 1
GS22FA40 GS22AFA60
18 PRESSURESWITCH 1
N/A N/A
19 VALVEBRACKET 1 2304624 2304624
20 BASEASSEMBLYBLACK 1 2304923 2304923
21 POWERCORDASSEMBLY 1 2201368 2101670
22 GASCONNECTORINLET 1 2304831 2304831
23 CAPACITOR 1 2201372 2201372
24 BASELOWERBLACK 1 2304925 2304925
25 KNOBGASVALVEBLACK 1 2101451 2101451
26 HEIGHTCONTROLLERBLACK 1 2304927 2304927
27 HEIGHTCONTROLSCREWBLACK 1 2304510 2304510
28 LEADWIREASSEMBLY 1 2201371 2201371
29 SPARKMODULE 1 N/A 2201391
30 PCBASSEMBLY 1 2201369 2201369
REG&HOSEASSEMBLY10FT(3M) 1 KR106021031 KR106021031
REG&HOSEASSEMBLY10FT(3M)w/HANDWHEEL 1 KR10602HW1031 KR10602HW1031
REG&HOSEASSEMBLY(QCC)10FT(3M) 1 KR10602HW1031 KR10602HW1031
REG&HOSEASSEMBLY15FT(4.6M) 1 KR106021531 KR106021531
REG&HOSEASSEMBLY15FT(4.6M)w/HANDWHEEL 1 KR10602HW1531 KR10602HW1531
REG&HOSEASSEMBLY(QCC)15FT(4.6M)
1 TYQ9C4572 TYQ10C4572
*VERSIONNOTSHOWNINEXPLODEDVIEW
31
ITEMNo.
DESCRIPTION
QTY
PARTNUMBER
PROPANE CONSTRUCTION HEATER
REPLACEMENT PARTS LIST
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
