Dyna-Glo LPFA40WH - Page 16

LPFA125WH
LPFA150WH
1 INNERSHELLASSEMBLY 1 2304929 2304929
2 NOZZLE 1 5030077 2304944
3 FLAMECAP 1 2325122 2304931
4 THERMALSWITCHBRACKET 1 2315515 2001355
5 THERMALSWITCH 1 2201373 2201373
6 NOZZLENUT 1 2304945 2304945
7
SPARKPLUGASSEMBLY
1 2206034 2201393
8
THERMOCOUPLEASSEMBLY(1130/1474425L)
1 2304885 2304885
9
GASTUBINGASSEMBLY
1 2325138 2304947
10
OUTERSHELL
1 2315916 2315916
11
CORDWRAP(selectmodelsonly)
2 2101423 2101423
12
HANDLEASSEMBLYBLACK
1 2101447 2101447
12.1
SCREWHANDLEFRONT
1 2001355 2001355
12.2
SCREWHANDLEFRONT
1 2001077 2001077
12.3
NUTHANDLEREAR
1 2000384 2000384
13
MOTORSUPPORT
1 2304823 2304823
13.1
MOTORMOUNTINGBOLT
2 2001332 2001332
13.2
SLEEVE
1 2304949 2304949
14
MOTORASSEMBLY
1 2304548 2304548
14.1
MOTORFAN
1 2304936 2304936
15
FANGUARDBLACK
1 2304939 2304939
16
MOTORBRACKET
1 2304938 2304938
17 VALVEGAS 1 GS22AFA125 GS22AFA150
18
PRESSURESWITCH
1
2305976 2305976
19
VALVEBRACKET
1 2304624 2304624
20
BASEASSEMBLYBLACK
1 2304924 2304924
21
POWERCORDASSEMBLY
1 2101673 2101673
22
GASCONNECTORINLET
1 2304831 2304831
23
CAPACITOR
1 2301390 2301390
24
BASELOWERBLACK
1 2304926 2304926
25
KNOBGASVALVEBLACK
1 2101451 2101451
26
HEIGHTCONTROLLERBLACK
1 2304928 2304928
27
HEIGHTCONTROLSCREWBLACK
1 2304510 2304510
HEIGHTCONTROLSCREWORANGE
1 2305467 N/A
28
LEADWIREASSEMBLY
1 2201371 2201371
29
SPARKMODULE
1 2201391 2201391
30
PCBASSEMBLY
1 2201369 2201369
REG&HOSEASSEMBLY10FT(3M)
1 GR1091038 GR1091038
REG&HOSEASSEMBLY10FT(3M)w/HANDWHEEL
1 GR109HW1038 GR109HW1038
REG&HOSEASSEMBLY(QCC)10FT(3M)
1 TYQ6D13000 TYQ6E13000
REG&HOSEASSEMBLY15FT(4.6M)
1 GR1091538 GR1091538
REG&HOSEASSEMBLY15FT(4.6M)w/HANDWHEEL
1 GR109HW1538 GR109HW1538
REG&HOSEASSEMBLY(QCC)15FT(4.6M)
1 TYQ6D14572 TYQ6E14572
*VERSIONNOTSHOWNINEXPLODEDVIEW
ITEM
No.
DESCRIPTION
QTY
PARTNUMBER
31
* VERSION NOT SHOWN IN EXPLODED VIEW
PROPANE CONSTRUCTION HEATER
REPLACEMENT PARTS LIST
