HDMI™ out port HDMI™ out port can connect with Type A
connector HDMI™ cable.
Memory media slot This slot lets you insert a micro SD™/SDHC™/
SDXC™ memory card. Refer to the Memory
media section for more information.
Keep foreign metal objects, such as screws, staples, and paper clips, out of
the Memory media slot. Foreign metal objects can create a short circuit,
which can cause damage and fire, possibly resulting in serious injury.
Headphone/
Microphone jack
A 3.5 mm mini headphone/microphone jack
enables connection of a monaural microphone,
stereo headphones, or a headset.
Right side
The following figure shows the right side of the computer.
Figure 3-3 The right side of the computer
1. Smart Card slot* 3. Security lock slot
2. Universal Serial Bus (USB 3.2 Gen1)
port
* Provided with some models.
Product appearance depends on the model you purchased.
Smart Card slot This slot allows you to install a Smart Card
device. Some models are equipped with a Smart
Card slot.
Universal Serial Bus
(USB 3.2 Gen1) port
Two type-A Universal Serial Bus ports, which
comply to the USB 3.2 standard, are provided on
the right side of the computer.
The USB 3.2 port is compliant with USB 3.2
Gen1 standard and backward compatible with
USB 2.0 devices.
The port with the icon ( ) has Power Off and
Charge function.
User's Manual 3-3
