*) For Type = Allpass: Slope = 6: First Order Allpass
Slope = 12: Second Order Allpass
Example: /ID3/ OUT1/ XOVER/ HIPASS/ FREQ 1500
Command Parser Code Table
UNIT-ID Tree Value Unit
/ID1/
IN1/
DELAY 1.927... 900.0 ms
EQ1/
FREQ 20 ... 20000 Hz
GAIN -12 ...12 dB
QUAL 0.4 ... 20.0
SLOPE 6,12 dB/Octave
TYPE
BYPASS,PEQ,LOSLV,
HISLV,HIPASS,LOPASS
EQ2/ ... EQ5/ see EQ1/
IN2/ see IN1/
INSUM/
DELAY 1.927 ... 900.0 ms
OUT1/
EQ1/
FREQ 20 ... 20000 Hz
GAIN -12 ... 12 dB
QUAL 0.4 ... 20.0
SLOPE 6,12 *) dB/Octave
TYPE
BYPASS,PEQ,LOSLV,
HISLV,HIPASS,LOPASS, ALLPASS
EQ2/ ... EQ4/ see EQ1/
XOVER/
HIPASS/
FREQ/ 20 ... 20000 Hz
TYPE/
THRU,6DB,12DBQ0.5,
12DBQ0.6,12DBQ0.7,
12DBQ0.8,12DBQ1.0,
12DBQ1.2,12DBQ1.5,
12DBQ2.0,
LINKW12DB,BESSEL12DB
BUTTER12DB,BESSEL18DB
BUTTER18DB,LINKW24DB,
BESSEL24DB,BUTTER24DB
LOPASS/ see HIPASS/
DELAY 0 ... 900.0 ms
POLARITY NORMAL,INVERTED
LEVEL OFF, -30 ... 6 dB dB
LEVREL -36 ... +36 dB
ROUTING IN1,IN2,IN1+2
MUTE 1,0
COMPRESSOR/
RATIO
1OVER1.0,1OVER1.4,
1OVER2.0,1OVER4.0, 1OVER8.0
THRESH -30 ... 0 dB
ATTACK 0 ... 99 ms
RELEASE 50 ... 999 ms
LIMITER/
THRESH -30 ... 0 dB
RELEASE 50 ... 999 ms
LEDS/
SUB ON, OFF
LO ON, OFF
MID ON, OFF
HI ON, OFF
OUT2/ ... OUT4/ see OUT1/
MISC/
DELAY_IN_UNIT US,MS,FEET,INCH,M,CM
DELAY_OUT_UNIT US,MS,FEET,INCH,M,CM
TEMPERATURE -4 ... 140 °F
TEMPERATURE_UNIT CELSIUS,FAHRENHEIT
PROGNAME
Up to 16 Characters
(ASCII Code <= 7Fh)
/ID2/ ... /ID32/ see /ID1/
