• High shelving filter ±15 dB / 12 kHz
Master EQ 7-band (63, 160,
400, 1k, 2.5k, 6k, 12k Hz)
±10 dB / Q = 1.5
Filter
• Low-cut filter, microphone
processing (switchable)
80 Hz, 18 dB/oct. or 150 Hz,
12 dB/oct.
• Low-cut filter, amplifier
(engaged in Direct Drive
mode)
50 Hz or 70 Hz, 18 dB/oct.
• Speaker processing LPN, switchable
Delay MASTER B, selectable 0–145 ms (0–50 m)
Effects
• Type Stereo 24/48-bit multi effects
processor
• Effect presets 32 factory presets, user editable
• Remote control Footswitch
Display 128 x 64 pixels, LCD
Audio player (USB at front panel)
• Switching mode power
supply (μC controlled)
FAT 32
• Supported audio file
formats
MP3, WAV
• Interface USB2.0, female type A
• USB power supply, max.
rated current (short
circuit proof)
5 V, 500 mA
Digital audio interface (USB at rear panel)
• Channels 2 in, 2 out
• AD/DA conversion 16-bit, delta-sigma
• Sampling rate 32/44.1/48 kHz
• PC interface USB2.0, female type B
Protection
• MASTER A, B, AUX
outputs
Adjustable peak limiters, -10 –
+11 dBu
• Amplifier Audio limiters, high temperature,
DC, HF, short circuit, peak
current limiters, turn-on delay,
back EMF
• Switching mode power
supply (μC controlled)
Inrush current limiters, mains
over/undervoltage, mains over
current, high temperature
Cooling Continuous speed controlled fan
Phantom power, switchable 48 V DC
AC power input 100–240 V AC, 50–60 Hz
Power consumption, at 1/8
maximum output power, 4 Ω
180 W
Safety class I
Operating temperature 5° to 40° C (40° to 105° F)
Product dimensions (Width x
Height x Depth)
395 x 244 x 241 mm
Rack-mount: 483 x 223 x 310.3
mm (7 HU)
Net weight 4.9 kg
Shipping weight 6.4 kg
* Device in rated condition: MIC GAIN 15 dB, STEREO GAIN LO, all
channel and master controls in center position, 100 V Direct Drive
mode: Off, LPN HIGH, amplifier load 8 ohms, dual channel, mains
voltage 230 V/50 Hz or 120 V/60 Hz, unless otherwise specified.
3 | PM 502
