DEVICE DESCRIPTIONS
5-34 PROMATRIX System User Handbook 1.1
5.2.5 Key-Labeling
Labeling the keys of paging consoles is done using label-strips, which can be slid in from the side. The label-strips
for the 6 or 8 function keys are slid in from the right while the selection key strips – for 10, 20, 30, or 50 selection
keys – are inserted from left. Therefore, you have to detach the correspondent side panel (2 screws) and insert
the labeled strip into the gap between the front panel and the front panel foil.
The most convenient way of printing the labels is to utilize the word processing software MS-WORD. A suitable
MS-WORD template file is supplied. Please note that with different printer models margin-settings may vary.
Please adjust the layout form according to the individual specifications of your printer model.
Tested printer models are: HP LaserJet 6P
HP LaserJet 5
HP LaserJet II
The recommended paper thickness is between 120 g/m
2
and 200 g/m
2
.
Also supplied with this handbook are prepared label-strips in German, English and French as well as empty strips
which only have to be cut out. You can label the empty strips in handwriting or by using Letraset
®
letters.
