DEVICE DESCRIPTIONS
PROMATRIX System Benutzerhandbuch 1.1 5-49
5.2.14 Cable Length
Depending on the utilized paging station model and amount, and in relation to minimal supply voltage and cable-
diameter, different maximum cable lengths are possible. The following tabulations show some examples for
cable-diameters of 0.6 mm and 0.8 mm and with supply voltages of 24 V, respectively of 21.6 V in emergency
supply operation. For precise calculation, a calculation-chart running under MS-EXCEL 97 is provided.
A Single Paging Station On A Single DPM-Line:
Cable type Paging console model Cable length (m)
21.6 V emergency
supply
Cable length (m)
24 V
JY(St)Y 4x2x0,6 DPC4510/4106 230 395
DPC4520 225 385
DPC4550 220 375
JY(St)Y 4x2x0,8 DPC4510/4106 410 700
DPC4520 400 690
DPC4550 390 670
A Single Paging Station + Extension On A Single DPM-Line:
Cable type Paging console model Cable length (m)
21.6 V emergency
supply
Cable length(m)
24 V
JY(St)Y 4x2x0,6 DPC4510 + DPC4350 150 260
DPC4520 + DPC4350 150 255
DPC4550 + DPC4350 145 250
JY(St)Y 4x2x0,8 DPC4510 + DPC4350 270 460
DPC4520 + DPC4350 265 455
DPC4550 + DPC4350 260 450
Four Paging Stations DPC4550 (+ Extensions) On A Single DPM-Line:
Cable type Paging console model Cable length (m)
21.6 V emergency
supply
Cable length (m)
24 V
JY(St)Y 4x2x0,6 4 x DPC 4550 55 95
4 x DPC4550
+ 4 x DPC4350
25 40
JY(St)Y 4x2x0,8 4 x DPC 4550 95 165
4 x DPC4550
+ 4 x DPC4350
40 75
