DEVICE DESCRIPTIONS
5-74 PROMATRIX System User Handbook 1.1
5.5.4 DCS 406R SCHIELDING MODULE
The module is meant for insertion on the rear of the DCS 400 base unit providing shielding between 100V - and
LF-modules.
Installation Notes
Always equip slots 1-10 of a DCS 400 base unit in ascending order (from the left to the right) leaving no empty
slots in-between.
Combining modules of different type is possible.
Exception: Slot 1 (the slot all the way on the left) always needs to be equipped with a DCS 401R control module
or a DCS 405R extension module.
Mounting the module and establishing the connections are solely admissible when performed in accordance to
VDE 0100 and EN 60065 regulations.
Specifications:
Dimensions (W x H x D) 37.5 x 80.6 x 245 mm
Weight 71 g
