Page 15
3101C Gen II MANUAL
11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C
DELAYED
EGRESS LOCK
(GENERATION II)
EXPLODED PARTS VIEW LEGEND
ITEM DESCRIPTION PART #
1 Fas-Trak Baseplate 300011
2 #10x1” Self-Tapping Screw *
2 10-24x1/2” Machine Screw *
3 Lock Housing
4 Access Cover & Sensor Assembly 301037
5 8-32x3/8” Machine Screw 300608
6 1/4-28x1/4” Set Screw 300604
7 Electronics Cover 300549
8 6-32x1/2” Pin Torx Security Screw 700174
9 End Cover 300010
* Part of Hardware Kit (301556)
Refer to Page 14 for parts locations.
ITEM DESCRIPTION PART #
10 Armature Mounting Plate Assy. 301038
11 Sensor Adjustment Wheel & Stud 301383
12 Wheel Stop 301003
13 8-32x1/2” Wheel Stop Screw 301005
14 #10x1” FHS Mtg. Plate Screw *
15 Armature Housing w/ pads 301334
16 8-32x3/8” Armature Mtg. Screw *
17 Disc Magnet (DSM only) 301289
18 Armature 300373
19 Compression Spring *
20 0.360”L Armature Spacer *
21 5/16-18x1” Armature Bolt (turned) *
