3101C Gen II MANUAL
11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C
DELAYED
EGRESS LOCK
(GENERATION II)
INDICATOR & AUDIBLE DESCRIPTIONS
BUILT-IN KEYSWITCH OPERATION
CENTER
CLOCKWISE (SPRING LOADED)
COUNTER-CLOCKWISE
NORMAL / LOCKED
RESET AFTER DELAY EGRESS ALARM
BYPASS / UNLOCKED WITHOUT ALARM
POSITION DESCRIPTION
CONDITION AUDIBLE SIGNAL LOCK COVER LED
DELAY EGRESS ALARM One second pulse rate during
delay cycle.
ON BLINK RED
DELAY EGRESS ALARM Steady tone after delay until
reset.
OFF GREEN
FIRE ALARM
RELEASE
Steady tone until re alarm
contacts are reset.
OFF GREEN
OPTIONAL REMOTE
AUTHORIZED BYPASS
(TERMINALS 7&8 / 9&10)
None, unless bypass audible
is enabled (dip switch 2). If
door is held open past relock
time, goes into delay egress
alarm & requires reset.
OFF BLINK GREEN
POOR MAGNETIC
BOND
Rapid pulse rate until problem
is corrected (only functional
with Dynastat Force Sensor
option).
N/A FAST BLINK RED
