Vent
I/O Interface
A/C IN
Switch
RS232
3000 nit
1000 nit
Step 11.1 Connect & Organize pre-mounted cables
LAN-1
USB-1
HDMI-1
INSTALLATION
GUIDE
Stretch out the cables in the channel on bottom of
the display, and place them as illustrated.
(Refer to the Step 11.2)
LAN-2
USB-2
HDMI-2
* connect to 1000 nit display
** connect to 3000 nit display
Vent
