5000 Top Side Control Instructions
17
Summary of control panel
parameters
FSxx Filter cycle start time
Fdxx Filter cycle duration
FFxx Filter cycle frequency
ESxx Economy mode start time
Edxx Economy mode duration
Tu X Temperature unit
LocX Control pad lockout
This function allows you to prevent unauthorized parameter
setting of the unit. This feature is especially helpful when young
children have access to the keypad.
There are two modes you can choose from: Full lock or Partial
lock. Full lock means that all keypad functions are locked. Partial
lock means that the basic functions of the spa will remain accessi-
ble (pumps, blower and light), but it will be impossible to change
the temperature Set Point, to override the Economy mode or
to enter the Programming mode.
When control pad is locked, the "Lock" icon will be displayed.
Locking your digital control pad:
1- Press and hold Pump 1 key for
5 seconds.
2- The display will show LocP, with "P"
representing Partial lock.
3- Release the key and the keypad will be
in Partial lock mode. Keep key pressed
down for 5 more seconds if you want
to be in Full lock mode. The "LocF"
message will then be displayed.
When control pad is locked, all automatic functions of the
system run as usual. If a key is pressed down, a "LocP" or "LocF"
message will be displayed for 1 second. To unlock the keypad,
simply press and hold Pump 1 key again for 5 seconds.
Digital control pad lockout
LocP
LocF
Inverted display
Press and hold Pump 2 for 5 seconds to invert the display. Note
that the ˚F or ˚C icon is not displayed in reverse mode. Follow
the same procedure to return to default mode. If a power-up
occurs, the display always returns to default mode.
Economy mode
Press Econo key to switch from Normal mode to Economy
mode. To save energy, the Economy mode Set Point is 20˚F
(11˚C) below the Normal mode Set Point.
The "Economy Mode" icon lights up when Economy
mode is on.
There are 3 available Economy operating modes:
noEc:No Economy mode
Ec 1:Economy mode on during a programmed
number of hours ( see Steps 5 & 6*)
Ec 2:Economy mode always on
Selecting the desired Economy mode:
1- Press and hold Econo key for
more than 2 seconds.
2- The display will show the current
mode (noEc, Ec 1 or Ec 2).
3- Keep key pressed down until the
desired mode is displayed.
After 5 seconds, the new setting will be programmed.
Ec 1
noEc
