Specifications M14-13655-EN
2-2
Specifications
Impact Velocity:
Gravity
(GRAV) mode 2.0 to 12.7 ft/sec
(1,440 to 9,144 in/min;
.61 to 3.87 m/sec;
3,658 to 23,225 cm/min)
Pneumatic (PNEU) mode 12.7 to 44 ft/sec
(9,144 to 3l,680 in/min;
3.87 to 13.41 m/s
23,225 to 80,467 cm/min)
Drop Weight:
5.5, 10, 25, 50, 75, 100 lbs.
(2.5, 4.5, 11.3, 22.7, 34.0, 45.3kg)
Impact Energy:
Gravity (GRAV) mode 0.5 to 223 ft-lb. (.67 to 302 Joules)
Pneumatic (PNEU) mode 14.0 to 326 ft-lb. (19.0 to 442 Joules)
Overall Dimensions:
Height 107.06 inches (272cm)
Width 23.0 inches (58.4cm)
Depth 29.3 inches (74.4cm)
Power Requirements:
Standard 120V, 60 Hz, 15 AMPS
Optional 220V-240V, 60 Hz, 10 AMPS
220V-240V, 50 Hz, 10 AMPS
100V, 50 Hz, 20 AMPS
Air Requirements:
Pressure 85-95 psi (585 - 650 kPa)
Flow
1.0 SCFM (28 L/min at atmospheric
pressure)
