Securing the Model 8250 in Place
3-5
Securing the Model 8250 in Place
When you are ready to secure the Model 8250 in place, move the machine onto the
foundation and bolt it to the floor with 1/2-13 (M12) stainless steel hardware. If
necessary, use machine grout and shims to level the Model 8250. The entire baseplate
must contact the foundation.
WarningWarning
Install the “H” bar to prevent the crosshead from falling before workingInstall the “H” bar to prevent the crosshead from falling before working
within the safety enclosurewithin the safety enclosure
The model 8250 is supplied with a safety "H" bar for the protection of the user. The "H"
bar clips to the guide columns and prevents the crosshead from falling. Use caution when
working in or around the model 8250 machine. Before working within the safety
enclosure, lift the crosshead beyond the height of the "H" bar and securely install the "H"
bar on the guide columns.
