Installing the Crosshead Weights
Each standard Model 8250 impact test machine is equipped with the following weight
sets:
1 set 5.5 lbs. (2.5kg)
l set 10.0 lbs. (4.5kg)
1 set 25.0 lbs. (11.3kg)
1 set 50.0 lbs. (22.7kg)
2 sets 25.0 lbs. (11.3kg) (with dowel pins)
The exact mass of each crosshead configuration is labeled on each weight set.
The following sections provide information on installing weights. Refer to Figure 5-3 for
an illustration of installing the add-on weights.
Figure 5-3. Installing the Add-on Weights
