Technical specifications
Parameter Value
Input level for 85 dB SPL @ 1 m, @ 0 dB setting,
unbalanced
80 mVrms
Max input level (@setting)
4,8 Vrms (-10 dB)
1,5 Vrms (0 dB)
1 Vrms (+4 dB)
Power consumption
Standby: 0.3 W
Idle: 5.8 W
Max: 94 W
Amplifier power
Tweeter: 50 W
Woofer: 50 W
Max SPL 1 m, normal room, short term IEC signal 118 dB peak
Frequency Response (+/- 3 dB) 42 Hz to 24 kHz
Resonance Frequency 45 Hz
Internal Cabinet Volume 9.5 liters
Bass Principle Bass reflex
Weight 7.7 kg
Dimensions (Depth x Width x Height) 296 x 186 x 320 mm
Crossover 2 way
Crossover Frequency 1900 Hz
Crossover Slope 12 dB/oct
Connection XLR balanced and RCA unbalanced
Recommended Placing Desktop
Tweeter
D-281 – 28 mm soft dome, rear chamber, magnetic
fluid
4 mm aluminum front
Pure aluminum wire voice coil
Woofer
180 mm molded aluminum frame
One piece thermo formed MSP cone
75 mm voice coil with pure aluminum wire on aluminum
former.
Cabinet
Designed to be placed on a desk.
18 mm MDF
Crossover Active, DSP based
Amplifier
Input sensitivity selector
HF, MF and LF trim selector
High pass frequency selector
Auto standby/On selector
Optional remote volume control (cabled)
High eciency digital power amplifiers.
Switch mode power supply with wide range input
Due to continuous development, these specifications are subject to change without notice.
14 BM User manual
