B51100 User Manual
7
2 Product Specification
2.1 Size and Weight
Table 2-1 B51100 Device size
2.2 Performance Parameter
Table 2-2 B51100 performance parameter
Item
Parameter value
Nominal Voltage(V)
51.2
Nominal Capacity(Ah)
100
Nominal Energy(kWh)
5.12
Recommended Charge/Discharge Current (A)
50
Max. Power Charge/Discharge Current (A)
80
Peak Power Charge/Discharge Current (A)
100 (15S)
Charge Voltage (Vdc)
56.5
2.3 Interface Definition
This section elaborates the interface functions of the front interface of the device.
Figure2-1 The sketch of interface.
Product
Nominal
Voltage
Nominal
Capacity
Dimension
Weight
B51100
DC51.2V
100Ah
481×535×140mm
≈44kg
