DL5.0C User Manual
©Dyness reserves the copyright of this document
24
Figure 3-15
Note:
1. For more ADD Settings，please refer to P7 “DIP switch definition and description”
Power cable-
Positive
Circuit
Breaker
Parallel cable-
Positive
Master Setting 1
Master Setting 2
Master Setting 3
Master Setting 4
Inverter
Communication
Cable to inverter
Communication
Parallel cable
Slave Setting 1
