Dyness Tower ESS - Equipment Installation Steps

Tower ESS Unit User Manual
17
3.6 Equipment installation
Table 3-2 Installation steps
Tower BDU
504*380*156.5mm
1 PCS
Battery Module
HV9637
96V/37Ah
504*380*240mm
4 PCS
Tower Base
504*380*186mm
1 PCS
Communication
cable to inverter
Standard,Black
/L2000mm /RJ45
plug at both sides
1 PCS
Cross recessed
countersunk
head screw
M4*10
20 PCS
User Manual
28Page
1 PCS
Power cable
connector
To positive pole of
battery
1 PCS
Power cable
connector
To negative pole of
battery
1PCS
Power cable
Positive cable
6mm²,red,2m
1 PCS
Power cable
Negative cable
6mm²,black,2m
1PCS
