Dynex DX-MLET21 - Dimensions; Tools Needed for Installation; Installation Tools Overview; Specific Drill Bit Requirements

3
DX-MLET21
www.dynexproducts.com
Dimensions
Tools needed
You need the following tools to install your new TV wall mount:
16.50 in.
(419.1mm)
29.20 in.
(741.6 mm)
5.02 in.
(127.6mm)
2.73 in.
(69.5mm)
2
.
7
3
i
n
.
(
6
.
9
c
m
)
(
c
o
l
l
a
p
s
e
d
)
2
5
.
6
i
n
.
(
6
5
.
1
c
m
)
16.5 in.
(41.9 cm)
5
.
0
2
i
n
.
(
1
2
.
8
c
m
)
(
e
x
t
e
n
d
e
d
)
Edge-to-edge
stud finder
Phillips
screwdriver
Measuring
tape
Drill
7/32 in. (5.5 mm) wood
drill bit (for wood stud
wall)
Hammer
Tape
Pencil
1/2” (13 mm)
Socket wrench
Awl
OR
3/8 in. (10 mm) masonry
drill bit (for concrete
wall)
1/2 in. (13 mm) drill
bit (for metal stud
wall)
OR
Level
