STEP 3 - Attach the mounting hardware to a TV
You’ll need
1 Align the left and right TV brackets with the screw holes on the back of your TV. Make sure that the brackets are level.
M4 x 12 mm
Phillips screwdriver
Screws Washers
TV brackets (2)
OR
M4 (4)
M6 x 12 mm
OR
M6/M8 (4)
OR
OR
M4 x 35 mm
M6 x 20 mm
OR
M6 x 35 mm
OR
M8 x 16 mm
M8 x 25 mm
M8 x 35 mm
M8 x 50 mm
OR
OR
OR
Spacers
OR
TV brackets
Tilt tension knobs
Top of TV
Important: Tilt tension knobs should be oriented to the outside edges.
TV brackets
