Product Operation
3-2 EFIS-D10A Pilot’s User Guide
Screens contain one or two pages and pages
contain groups of similar information.
Display
The EFIS-D10A display is the most obvious and commonly used output of the device. It is capable of displaying EFIS,
HSI, and/or engine data simultaneously.
SCREENS AND PAGES
The terms in the following bulleted list are used in this section and are defined as follows:
• Screen/Screen Configuration – Screens consist of one or two pages
from the EFIS-D10A or from another DSAB-connected Dynon
Avionics product.
• Page – A page is a section of the screen that contains a collection of
related data. Pages may occupy the total area of the screen (i.e.,
100%) or share the screen with other pages (i.e., 1/2 split).
• Screen Rotation – The rotation is the list of screen configurations
which can be cycled to via the hotkeys. Your rotation is usually
smaller than the total list of available screen configurations.
