Press the lower retaining clip from inside the UMC
to remove the cable collar.
Separate the collar from the cable.
To remove the bleed valve, carefully push out
from the outside of the UMC using a thin, flat
bladed screwdriver.
To replace the bleed valve, assemble in the above
order.
To remove either actuator or spring, unclip from the
inside of the UMC with the aid of a pair of long
nosed pliers.
To refit, locate the springs, then actuators from the
outside of the UMC, and firmly snap in.
Fitting notes
8
9
10
11
service manual
