Dyson DC25 Service Manual

Fitting notes
Service manual
08
08 To fit, locate the spring onto the
retainer. Locate the cap onto the
spring. Push the cap down onto
the catches.
09 Remove the three screws in the
upright switch cover.
10 Remove the upright switch cover.

Dyson DC25 Specifications

General

Type	Upright
Cyclone Technology	Root Cyclone
Ball Technology	Yes
Filter	HEPA
Bagged/Bagless	Bagless
Suction Power	220 AW
Warranty	5 years
Dust Capacity	0.32 gallons
