Dyson purifier cool Gen1 User Manual

Information menu
Filters
Particulate matter (PM10)
The remaining filter life is shown
on the LCD screen and will indicate
when your filters need replacing.
Larger microscopic particles up to 10 microns
in size, suspended in the air we breathe. These
include dust, mould and pollen.
Particulate matter (PM2.5)
Microscopic particles up to 2.5 microns in size,
suspended in the air we breathe. These include
smoke, bacteria and allergens.
Indoor particulate matter – 12 seconds
Monitors the current particulate matter with a
graph showing the last 12 seconds of data.
Press this button to scroll through the information being monitored by your
Dyson purifying fan.
Information about particulate matter and filter levels is shown on the
LCD screen.
When a particular type of pollutant causes air quality to decrease,
a symbol for the pollutant will show on the LCD screen.
The remote control with
the information button
on the bottom right.

Dyson purifier cool Gen1 Specifications

General

Airflow	290 l/s
Air speed	1.2 m/s
Cord length	1.8 m
Sleep timer	Yes
Air purify rate	- m³/h
Number of speeds	10
Oscillation angle	350 °
Air purifiers functions	Fan, Heating
Noise level (low speed)	42.6 dB
Noise level (high speed)	61.4 dB
Timer duration (maximum)	8 h
Timer duration (minimum)	1 h
Suitable for room area up to	27 m²
Package depth	260 mm
Package width	257 mm
Package height	1103 mm
Package weight	6850 g
Battery type	CR2032L
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	- W
Power consumption (standby)	1 W
Fine particle (PM2.5) numeric reading range	12 µg/m³
HEPA class	HEPA 13
Filter life (max)	12 month(s)
Display type	LED
Product color	White

Weight and Dimensions

Depth	120 mm
Width	204 mm
Height	1050 mm
Weight	4730 g
Remote control weight	25 g
Remote control dimensions (W x H x D)	32.2 x 10.49 x 90 mm
