With the stick pulled back down, the swashplate should raise, decreasing the pitch of the main blades.
Mode 2 Mode 1
Position the helicopter to view it from the left or right side. Move the throttle/collective stick up and down to check
the collective pitch control. When the stick is pushed up, the swashplate should lower, increasing the pitch of the
main blades.
Mode 2 Mode 1
