3. Anti slide rubber feet-
Illustration as follow pictures, pull the pad-removing tab "J", separate
anti-sliding pad with leg.
J
I
H
G
D
C
B
A
J
Bowl base
Leg tube
Locking knob
Retractable easy hook
Mid spreader
Anti slide rubber pad-
Pad-removing tab
Foot with spike
Loose: turn locking knob "C" anti-clockwise
Lock: turn locking knob "C" clockwise
1.Loose lock leg tube
&
Important message: before unfold the tripod, please loose all the locking
knobs , then adjust it to your requested length and lock it. "C"
C
lock
loose
PARTS(AT7402A)
Important message: this spike foot is used for out door shooting
2.Adjusting tripod height
Loose all the locking knobs and extend the legs to your request height,
then lock knobs tightly.
USE AT7402A
17
18
