CLASS 1000 METER
62-0388-01 20
6.0 KWH METER FEATURES & FUNCTIONS
6.1 KWh Meter Display Functions
Fig. 10. Normal Mode (kWh Reading)
The Class 1000 kWh meter display requires no multiplier and shows kilowatt hours
consumed. See section 6.2 for information on calculating cost based on kWh usage.
Fig. 11. KW Load Mode (Current Load in kW)
The Class 1000 LOAD display shows the present circuit load in kilowatts.
Fig. 12. Start Up Mode
When initially powered on, the Class 1000 meter will display the startup screen.
This screen indicates the meter voltage, amps, and service configuration. It will remain
on for approximately five seconds before switching to the normal operating mode.
