CLASS 1000 METER
62-0388-01 28
10.0 METER TECHNICAL SPECIFICATIONS
Ordering Information: Define brand, class, input voltage, current sensor amperage,
enclosure type, and sensor type in the format A-B-CC-DDD-EEE-F-GGG where:
A = Brand: E for E-Mon, H for Honeywell
B = 10 for Class 1000
CCC = Numbers of conductors (including common/neutral): 2 or 3
DDD = Input Voltage: 120, 208, or 277
EEE = Amperage: 25,50,100 or 200
F = Enclosure Type: J = standard metal, R= 4X raintite, M = MMU
GGG = sensor type: KIT = split-core, SCS = solid core, ““blank” = none supplied
Input Voltage
Configuration
3-wire or 2-wire single phase
Mains Voltage Input Up To 277 VAC RMS Available
Input Power 2 VA Maximum Rating
Current Sensor
Rating
Up To 200 Amps RMS AC Available
Power Factor 0.5 Leading Or Lagging
Line Frequency 50-60 Hz
Metering Accuracy Certified To ANSI C12.20
Voltage Operating
Range
+/-10% Of Rated Load
Temperature Range (Standard indoor enclosure): -20C To +50C
Temperature Range (NEMA 4X outdoor enclosure):-20C To +70C
Relative Humidity
Range
0-95% Non-condensing
EXAMPLE:
E 3 10 208 100 J KIT
NUMBER OF CONDUCTORS
CLASS 1000 METER
INPUT VOLTAGE (208V)
AMPERAGE
ENCLOSURE TYPE (STANDARD METAL)
E-MON
3 SENSORS INCLUDED (SPLIT-CORE)
