E-Net E-P132-X - RS-422 Serial Port Pin Assignment; RS-485 Serial Port Pin Assignment

40
1 2 3 4
□
□
□
RS-422 Pin Assignment
The pin assignment scheme for given 4-pin of RS-422 below.
PIN 1 : T+ PIN 2 : T- PIN 3 : R+ PIN 4 : R-
□
□
□
RS-485 Pin Assignment
The pin assignment scheme for given 4-pin of RS-485 below.
PIN 1 : X PIN 2 : X PIN 3 : D+ PIN 4 : D-
1 2 3 4
