The folding / unfolding system may be different depending on the
product. There are 2 folding / unfolding systems:
- Pin system - Loop system
You will find below the details of the steps for each system.
3) Functions
a) Pin system : Folding / unfolding the handlebar
i) Pin system : unfolding the handlebar
- After unpacking the product, raise the steering column
(photos n ° 1 & 2 / p20)
- Lock the folding loop (photo n ° 3 / p20), the safety pin will
automatically position itself in the closed position.
- Unlock the handlebar locking buckle (photo n ° 4 / p20)
- Position the handlebars so that the brake handles are
horizontal (photo n ° 5 / p20)
- Re-lock the handlebar locking buckle (photo n ° 6 / p20)
