SHANGHAI ESURVEY GNSS CO., LTD.
19
It takes 4 hours to fully charge the battery:
Red indicator: the battery is in charging.
Green indicator: the battery is fully charged.
To charge the battery, do the following:
1. Put the charger plug on the switching adapter, and connect the switching adapter
and the charger.
2. Put the battery into the charger.
4.4 Connect to the External Power
Power supply from 5-pin port is supported, and the external battery within 9-28VDC is
required.
CAUTION: It is not used for charging. Please use the original cable provided by us
or cable with LPS standard.
To connect to the external power, open the cover of 5-pin port and connect one end of the
cable to the 5-pin port and another end of the cable to the external battery.
4.5 Install the Radio Antenna
The antenna is required when the datalink is set to internal radio.
To insert radio antenna, open the cover of UHF radio, and install the radio antenna.
