Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
2. Connect oil hoses according to the following diagram.
Don’t let any solid substance go into the hydraulic line.
Ensure the connectors are screwed tight against leakage.
Step 11: Install the electrical system.
Refer to electrical connection diagram before making the connection.
Attention: electrical system connection must be done by qualified electricians. .
1. Mount the control box on to the power side post.
