Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
2. Fix the limit switch onto the inside surface of the power side post.
Connect the wire of limit switch with the terminals reserved in the control box.
3.Connect the limit switch fixed at the cross beam.
4. Connect quick connectors between electromagnets.
1.Cross socket flat head screw M5*10
1.Cross socket flat head screw M4*25
