Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
32
Supply cable
Yellow-Green
Blue
Other colors
3 wires
Earth wire
Neutral wire
Phase wire
5 wires
Earth wire
Neutral wire
Phase wire
Supply cable
Yellow-Green
Other colors
4 wires
Earth wire
Phase wire
Pos.
CODE
Description
Qty
T
320102013
Transformer (dual 380V220V)
1
T
320102014
Transformer (dual 400V230V)
1
T
320102015
Transformer (dual 415V240V)
1
QF
320801003
Circuit breaker
1
QF1
320803003
Circuit breaker
1
QF2
320803006
Circuit breaker
1
KM
320901011
AC contactor
1
SQ1
320301002
Limit switch
1
SQ2
320301011
Limit switch
1
YA1,YA2,YA3,YA4
330310005
Electromagnet
4
QS
320304001
Main switch
1
SB3
320401038
Button
1
SB1,SB4
320401041
Button
2
SB2
320401042
Button
1
KA
320601026
Compact relay
1
KT
320602009
Compact time relay
1
C
321001004
Capacitor
1
VD
321002001
Bridge rectifier
1
HL
321201001
Power indicator
1
NOTE: For power supply of other voltages, the transformers are different.
Please check with our customers service people when order spare parts.
